Found a method to see inside some chips, without having to unmount or destroy the chips. Best part - the method only relies on lightly modded off-the-shelf cameras and lenses. Read more at

192,678 次观看 • 3 年前 •via X (Twitter)

10 条评论

Fritzchens Fritz 的头像
Fritzchens Fritz3 年前

Nice to see other people have also success with this method. Have been thinking for a while if an array of 16x 1070nm 100mv LEDs could achieve homogeneous illumination. But 12$ per LED + import fees are not a no-brainer compared to a cheap red light lamp.🤔

bunnie 的头像
bunnie3 年前

I agree about the pricing problem for the LEDs. If I find any cheaper LEDs I'll let you know. I want to use the LEDs in part because I'd like to digitally control the angle of the lighting, so an array of LEDs in a ring around the chip would be ideal, if it wasn't so expensive...

DiscoStarslayer 的头像
DiscoStarslayer3 年前

Hmm, I wonder if it's similarly possible to finagle some strategic bit flips using a IR laser? 🤔

bunnie 的头像
bunnie3 年前

Definitely. This technique is the poor man's version of existing techniques developed to do explicitly that.

Catherine 的头像
Catherine3 年前

this is so cool

Arsenio "Missileman" 的头像
Arsenio "Missileman"3 年前

That's pretty dang good. Love seeing beyond the vis. You can also see localized heating and regions with high res thermal as silicon transmission is 60% at LWIR

Zinjanthropus 的头像
Zinjanthropus3 年前

This vid has a strange beauty. (BTW, I had the pleasure of hearing you speak in BRC last year. I was the guy who asked the stupid question about C vs Rust; hope to see you again soon!)

Brian Boatright 的头像
Brian Boatright3 年前

that is amazing! you always post the best stuff. thank you

will whang🌻 的头像
will whang🌻3 年前

Here is one of the examples people using SWIR to take a die shot.

Rue Mohr 的头像
Rue Mohr3 年前

@DHammarskjold OOOoo I'v not tried my differential light source on something like that... try it on your hand for me would ya?
