Made this video (🎶) with a Midjourney v6 image! Started by upscaling/refining with Magnific.ai, pulled a Marigold Depth Map from that in ComfyUI, then used as a displacement map in Blender where I animated this camera pass with some relighting and narrow depth of field.🧵1/12

135,672 görüntüleme • 2 yıl önce •via X (Twitter)

11 Yorum

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

Here's the base image and the before/after in @Magnific_AI. Even though MJv6 has an upscaler, Magnific gave me better eyelid and skin details for this case. (Fun fact, this image was from a v4 prompt from summer last year, when MJ had just released a new beta upscaler.) 2/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

Next step was using the new Marigold Depth Estimation node in ComfyUI to get an extremely detailed depth map. Note that I'm saving the result as an EXR file (important for adjusting levels later), and that the remap and colorizing nodes are just for visualization. 3/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

To install, I just searched for Marigold with the custom node manager in the most updated version of ComfyUI. You can also refer to the GitHub repo. 4/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

I kept denoise and n_repeat at 10 initially then pushed the final to 40 & 30. I found that I got the best map detail around 1024 x 1024 resolution. Above 1600 I got muddy results, and above 2000 render times shot thru the roof/VRAM ceilings on my 4090 laptop. 5/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

I imported the EXR into Photoshop & used layers of level/curve adjustments to make the final TIFF file for Blender. I tried to create distance between the tip of the nose and the rest of the face. I did this by eye/trial & error, so it's something you'll need to tinker with. 6/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

To do the displacement in Blender, I basically followed this tutorial. It explains the process better than I can. 7/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

Note that the displacement map I ended up with wasn't a perfect reconstruction of a nose and lips. I used my camera angles/lighting to reduce how noticeable the displacement artifacts were. It's not as robust as a fully modeled scene obvs, but it's much faster to make. 8/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

Here's my shader setup/modifier stack in Blender. In the shader I used a high metallic value to up the contrast and make the shader pop in 3D lighting (similar to metallic photo prints.) Also, I gave the shader a low emission value to mix the original colors with relighting. 9/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

Then I added a red side light to accent things using a long, thin area light. I also keyframed a slowly strobing point light moving through the scene to showcase depth. Note how a low emission shader keeps detail in the shadows while allowing relighting to make changes. 10/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

I also used a camera with a f/0.8-2.0 aperture to get very narrow depth of field to create bokeh and further showcase depth and draw attention to the skin texture. Then edited to a Florence & The Machine song. 11/12

CoffeeVectors profil fotoğrafı
CoffeeVectors2 yıl önce

Hope this is helpful for some of you and let me know if you have any questions! And if you make something cool with these tools let me know! Would love to see how everyone is experimenting and pushing things forward! 12/12
