Vibe Coding Robotics Part 8 Built a hexapod simulator with Claude Opus 4.6 Based on an open source algorithm that works on real hexapod robots. UI design generated with Nano Banana. More details ↓

1. Instead of asking AI to write the algorithm from scratch, I wanted to see if Claude could take an existing hexapod algorithm from GitHub and implement it the way I wanted. I used Gemini in other parts, but from my testing, Claude works really well at transforming code from other repos, so I used Claude for this one.

2.This is the open source repo I used, created by Mithi Sevilla. (could not find them on X). I made a Next.js and shadcn version of this repo a couple of months ago while trying to understand the algorithm.

3. I copied code from one of my old robotics demos and from the hexapod repo into a single repo and used that as context for Claude. I asked it to reuse the algorithm from the original repo but build the visualization using techniques from my robotics demo.

4. The main difference is that the original repo uses Plotly, while I wanted to use three.js. That meant Claude had to write a whole new set of transform functions to convert data meant for Plotly into something usable in three.js.

5. I also asked Claude to convert everything it used from the original repo to TypeScript and to convert all classes into function based implementations. While I eventually reached a point with no TypeScript errors, I would call it a lazy conversion. React class components were converted to functional components successfully, but it struggled with classes in the core algorithm.

6. Overall, it did a good job and I got it working. I did have to review the code a few times and explain what went wrong when some fixes were clearly going nowhere.

7. Next time, I will probably try converting a simulation written in a language other than JS or TS to see what happens.

8. In case you missed it, here is the last part of the Vibe Coding Robotics series where I built Leonardo da Vinci's ornithopter.

9. I also have a series where I try to make games with AI. Here is the latest part of that series.
